AMD® Fusion Series APU
Support Dual 1080P Video Output with T56N or T48N
Hardware Decode for 1080P MPEG-2, H.264 and VC-1 Playback
Multiple video output: HDMI, VGA and LVDS with dual independent display
Support DirectX 11®, Support OpenGL 3.0
Mini-PCIe Support WIFI, 3G (with USIM Slot), Tvtuner Card
Processor System - CPU - AMD® G-Series APU Duo T40R - 1.0GHz/T40E - 1.0GHz
CPU Socket - Onboard
Front Side Bus - 800/1066/1333 MHz
Chipset - AMD® eBrazos + Hudson-M1
-
System Memory - Technology - Dual channel DDR3 800/1066/1333MHz FSB
Max.Capacity - Up to 1GB
Socket - Onboard
Display - Graphic Controller - AMD® RadeonTM HD6 series support DirectX® 11
LVDS - Support Dual channel 18/24bit
- Resolution: up to 1920 * 1200 （Support 1080P）
VGA - 1 * Onboard pin header 2 * VGA
- Resolution: up to 2560 * 1600
HDMI - N/A
- N/A
Display Port - N/A
- N/A
Dual Display - CRT+LVDS
Ethernet - Controller - LAN1: Realtek 8111E GbE LAN
LAN2: N/A
Audio - Controller - Realtek ALC662 HD audio codec（ Line-out）
Super I/O - Controller - SMSC3114
H/W Monitor - Watchdog Timer - Programmable 1 ~ 255 sec.; Support System reset
Smart fan - 1 * 3 Pin DC CPU Fan line control
TPM - Controller - N/A
I/O Interface - USB - 4 * USB 2.0/1.1
Serial - 4 * (3 * RS-232, 1 * RS-232 / RS-422 / RS-485)
Parallel - 1
PS/2 - 1
GPIO - General purpose 4 channels Input and 4 channels Output
IEEE 1394 - N/A
Expansion Slot - PCIeX16 - N/A
PCIeX4 - N/A
PCIeX1 - N/A
PCI104 - 1 * PC / 104 ;16 bit ISA Bus Slot
Mini-PCIe - N/A
USIM - N/A
Storage - SATA - 1 * SATAII, 1 * FPC SATAII
SSD - N/A
IDE - N/A
eSATA - N/A
Compact Flash - N/A
