Smart Design: Adapted for modular panels, can be DIN-rail mount or panel mount.
Digital and Analog Inputs:

•Digital up to 20Hz
0 to 10V or VCC: to control with direct voltage or potentiometers
LDR: direct connection of LDR light sensors
NTC: direct connection of NTC temperature probes
•4 Relay Outputs: Standard 8A outputs
•5 Static PWM Outputs: For DC motor speed control, AC

•Expand up to 50 I/Os: Expand your applications
•Embedded Highly Visible Screen: Good visualization - Bright blue screen or classic
•Programmable Buttons: Each button can be configured for a different function. Use front face button to execute action manually

SIMPLE
•Quick, simple and intuitive programming requires no specialist knowledge
•Self-teaching made easier thanks to a user-friendly online help guide and programming examples
•A simulation mode that consistently represents controller operation

POWERFUL
•A complete range of basic functions: counting, timing, comparison, display, logic, gain, sin/cos, etc are also available
•A wide range of dedicated functions: pump rotation, PID regulation, movement, pressure, level, water ratio, solar tracking, and flow

Parameter Name	Parameter Value
Type	compact DIN rail
Input/output	with integrated I/O, analog inputs, digital outputs, relay outputs
Other characteristics	modular
