About
Covers: Painted die-cast aluminum
Tube: Anodised aluminum
Seals: Polyurethane - NBR
Guide bush: Sintered bronze
Piston Rod: AISI303 stainless steel
Max pressure: 10 bar
Operating temperature: -20 ° C + 80 ° C with dry air
Fluid: Filtered and lubricated and non-lubricated compressed air
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
pneumatic
|
| Configuration |
|
| Material |
aluminum
|
| Norms |
ISO 21287
|
| Applications |
|
| Other characteristics |
compact
|
| Stroke (mm) |
5 - 500
|
| Force (N) |
188 - 4710
|
