About
Suitable for upper computer -
Computer PLC single chip microcomputer
Form a complete set of motor -
Stepper motor
The development environment -
VC C# Labviwe VB Linux Python
The power supply voltage -
DC12-48V
The largest segment -
0/256 is adjustable
Temperature resistance -
At 20 ℃ to 80 ℃ below zero
Maximum pulse frequency -
200K
Durability -
Over 20,000 hours
The input
General I/O -
Main product series
Function -
External stop input, electromagnetic brake control, digital input/output, analog input, factory reset, 5V output, digital ground
The input specifications -
Digital input voltage: 0-5v
Analog speed regulation input voltage: 0-3.3v
External limit input voltage: 0-24v
Control mode
Support control mode -
Position mode, speed mode, PV mode, PP mode, PVT mode, analog speed regulation, analog positioning, synchronous positioning
Mode switching -
Specified instruction switching
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| AC/DC |
DC
|
| Type |
stepper
|
| Voltage (V) |
36 - 24
|
| Number of poles |
single-pole
|
| Applications |
industrial
|
| Other characteristics |
|
| Torque (Nm) |
0.25 - 8.7
|
| Operating temperature (°C) |
20 - 80
|
