Application areas:
Crane systems
Offshore / Ship
Steel industry
Mining / Material handling
Storage technology
Wind industry
Railbound hall roofs / gates
Product type:
RKK - W / Shaft-, Claw coupling

Product description
Elastic shaft coupling, Claw coupling with brake drum for drum brakes according to DIN 15435
Coupling is positively and breakdown-resistant
Made from solid material (C45), NO casting design
Standard painting RAL 5009 (2-Components painting)
WITHOUT brake disc / brake drum
MADE IN GERMANY, own production

RKK couplings / Connecting element with high flexibility.

Torsionally flexible
Axial compensatively
Radial compensatively
Angular compensatively
Exchange of worn coupling elements / rubber elements:
1. Releasing retaining cap and retract
2. Remove worn coupling elements and insert new ones
3. Put back and screw tight retaining cap

Easily removable worn rubber elements / coupling elements WITHOUT disassemble the coupling or motor
Claws of the couplings are coaxial to the shaft (No draft angles, therefore lower axial forces)
Long service-life and reduced maintenance / follow-up costs
MADE IN GERMANY

Parameter Name	Parameter Value
Type	claw
Product applications	for shafts
Installation system	sleeve and shear pin
Torque (Nm)	0 - 0 300 - 300
Rotational speed (rpm)	1760 - 5700
