Industrial grade cellular LTE Cat 1 modem with rugged aluminium housing is a compact and easy to use connectivity device that can provide cellular capabilities to equipment across all market segments.

It is backward compatible with 3G and 2G, therefore it is an optimal choice when it comes to large scale connectivity upgrades for Industrial or Public infrastructures. It offers a long and stable lifecycle and low power consumption important for IIoT projects.

TRM240 comes with a USB interface for power and communication.

HARDWARE
Mobile - LTE (Cat1) / 3G / 2G
SIM slot - Mini SIM (2FF)
Antenna connector - 1 x SMA for LTE
Operating Voltage - 5V - powered via microUSB
Power consumption - 3.2 W Max
Configuration interface - microUSB
LED indicators - Power, Network and LTE status LEDs
Operating temperature - -40 °C to 75 °C
Operating humidity - 10 % to 90 % non-condensing
Casing material - Aluminium housing
Ingress Protection Rating - IP30
Dimensions (W x H x D) - 74.5 x 25 x 64.5 mm
Weight - 131 g
SOFTWARE
Management software - Windows Connection Manager (NDIS driver)
USB Serial Driver - Windows 7/8/8.1/10,
Windows CE 5.0/6.0,
Linux 2.6/3.x/4.1~4.14,
Android 4.x/5.x/6.x/7.x/8.x
RIL Driver - Android 4.x/5.x/6.x/7.x/8.x
NDIS Driver - Windows 7/8/8.1/10
Gobinet Driver - Linux 2.6/3.x/4.1~4.14
Linux qmi wwan Driver - 3.x (3.4 and later)/4.1~4.14
Protocols - TCP/UDP/PPP/FTP(S)/HTTP(S)/NTP/PING/QMI/SSL
INTERFACES
Management interface - AT Commands (3GPP TS27.007, 3GPP TS27.005)
Hayes AT Command set
Enhanced AT Commands

Parameter Name	Parameter Value
Type	cellular
Network	network 4G TCP/IP 2G LTE LTE Cat 1 internet 3G USB WWAN
Application	industrial aluminum profile
Mounting	mobile
Other characteristics	low-power
