Programmable CAN-Bus Electronic Control Units
CANbus ECU C.024: 8 Input - 8 Output
As AVIONI® Technologies, we produce master/slave electronic control units which are proper to use within multiplexed systems and earthmoving machines both.

All our electronic control units have double microcontroller in order to cross control of inputs and outputs behavior. As contemporary automotive standard, CANbus communication protocol is preffered. All AVIONI® electronic units have one or more CAN-Bus (based on both CANopen & SAE/J1939) port regarding the vehicle's requirements. As well as current feedback, over-current protection, over-voltage protection, reverse polarity protection and diagnostics of all input & outputs, internal watchdog safety relay is a standard feature of our master control units.

Our Electronic Control Units are designed according to comply with EN ISO 13849-1 at PL/D, which is the top level safety norm of the EU.
AVIONI® ECUs have CE Marking and comply with the following standards according to the latest EMC directive 2014/30/EU:
EN 55022:2010/AC:2011(RF Emission)
EN 55024:2010 (Electrostatic Discharge)
EN 61000-4-2
EN 61000-6-1
EN 61000-6-3

Parameter Name	Parameter Value
Options	CAN Bus programmable
