GENERAL SPECIFICATION
Winding type：YWE
Hall effect angle：120 Deg. Electrical angle
Radial play：0.025mm /460g
End play：0.025mm /400g
Max. radial force：115N @ 20mm from the flange
Max. axial force：45N
Insulation class：B
Dielectric strength：500VDC for one minute
Insulation resistance：100MΩ min., 500VDC
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| AC/DC |
DC
|
| Type |
brushless
|
| Voltage (V) |
24 - 24
|
| Number of poles |
8-pole
|
| Power (W) |
31.5 - 188
|
| Torque (Nm) |
0.36 - 1.8
|
| Rotational speed (rpm) |
1000 - 1000
|
