Plenty of I/O points -150 points max. [L40□ / L60

If the customer can not predict the number of I/O points needed by his machineries and devices in the future, he will feel hesitant and uncomfortable. But, the I/O number of FP-X0 can reach 150 points max. by using the FP-X expansion unit. Therefore, the customer's discomfort and hesitation can be eliminated.
(L14R and L30R don't have the expansion function, so they can not be expanded.)

• The maximum number of expansion unit is up to 3 units.
Further expansion and more functions achieved by using the existing FP0R expansion unit easily [L40□ / L60

The maximum number of FP0R expansion unit is up to 3 after the control units are equipped with adapters.
A wider range of application can be achieved by using [transistor output], [analog I/O], [thermocouple input] and [I/O LINK (network.
Only one FP0 expansion adapter can be installed on the control unit.
In addition, two FP-X expansion units can be installed after the adapter is installed. (L14R and L30R don't have the expansion function, so they can not be expanded.)

Super-high processing speed

Super-high speed of 80 ns/step for 0 to 3,000 steps (ST command). 580 ns/step processing speed for 3,001 steps or more (Only for L40□ and L60□).

Pulse output function / High-speed counter function

The pulse output function of FP-X0 (1-axis for L14R and 2-axis for L30R / L40□ / L60□) is built in the body of the control unit.
Compared with the previous PLC that must use the advanced or specific positioning units or more than two multi-axis control devices, FP-X0 only uses one unit basically, thus saving the space and reducing the cost.

Parameter Name	Parameter Value
Type	box
Input/output	with integrated I/O
Network	RS485 RS232 for fieldbus
Other characteristics	high-speed multi-axis
