Product Features
BT 5.0
Frame rate 120fps
4 mil resolution
Working distance up to 70M

USB Dongle interface: - USB-KB / USB-COM
Barcodes supported (1D): - All UPC/EAN/JAN, Code 39, Code 39 full ASCII, Code 32/ Italian Pharmacode, Code 128, CODABAR, Interleaved 2 of 5, MSI, Code 93, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Limited, Industrial 2 of 5, Matrix 2 of 5
Barcodes supported (2D): - PDF417, Micro PDF 417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec
RF Standard: - Bluetooth 5.0
Working Distance: - 70M (Open environment)
Optical System: - 640 (H) x 480 (V) pixels
Light Source: - Aiming red LED, 6000-6500k white illumination LED
Resolution: - 4 mil (Code 39), 6.67 mil (Datamatrix)
Frame Rate: - 120FPS
Field of View: - Horizontal: 28°; Vertical: 36°
PCS: - 30%
Indicator: - Beeper, LED, Vibration
Voltage: - DC 3.3V
Currents: - Power off: 27uA , Standby:150mA , Scaning:200mA
Operating Temperature: - -40℃ to 70℃(-4℃ to 158 F)
Storage Temperature: - ˚ -40℃ to 70℃(-4℃ to 158 F
Operating Humidity: - 10% - 95% RH (Non-condensing)
Storage Humidity: - 10% - 85% RH (Non-condensing)
Drop: - 1.5m drops
Light Level: - 100,000 lux
Weight: - 145g
Dimension: - 185.48mm (L) x 66.57mm (W) x 90.83mm (H)
Housing Material: - ABS plastic
Cable: - Length: 5ft (150cm) / USB Type A
Warranty: - 1 year
Certificate: - FCC , TELEC , NCC
Battery Type: - Polymer 3.7V 1050mAh
Battery Capacity: - 1050mAh good for 21,000 scan per charge
Charge: - By USB power retrieving cable
Time of Charge: - About 4 hours

Parameter Name	Parameter Value
Portability	handheld
Type	1D 2D
Other characteristics	Bluetooth
Measuring distance	Min.: 0 mm (0 in)Max.: 70,000 mm (230 in)
