Additional information
Rated Voltage V:24
Rated Torque Ncm:4 / 8
Speed rpm:3000

Technical Data
Model:BL28.47S;BL28.67S
Rated Voltage (V):24;24
Rated Speed (min1):3000;3000
Rated Torque (Nom):4;8
Rated Power (W):12.5;25
Rated Current (A):0.8;1.6
Peak Current (A):2.4;4.8
Peak Torque (Nom):12;24
Rotor Inertia (gcm2):20;30
Torque Constant (Ncm/A):5;5
Back EMF (V/min1):4.5;4.5
Résistance (Q):2.5;3.4
Inductance (mH):1.1;1.3
Length (mm):47;67
Net Weight (kg):0.22;0.3
No. of Pôles:8
No. of Phases:3
Insulation Class:B

Parameter Name	Parameter Value
AC/DC	three-phase
Type	BLDC
Voltage (V)	24 - 24
Number of poles	8-pole
Power (W)	12.5 - 12.5 25 - 25
Torque (Nm)	0.04 - 0.04 0.08 - 0.08
Rotational speed (rpm)	3000 - 3000
Diameter (mm)	28 - 28
