Material Thickness：0.3～4.5 mm Note: Please refer to the correction ability table for thickness x width

Material Width：100 ～ 1800 mm

Yield Strength ：≤650 N/mm2

Coil Inner Diameter:Φ450~φ530mm/φ480~φ530mm/φ580~φ630mm

Coil Outside Diameter:max φ 1600 mm

Coil Weight:3000~15000kg

Standard accessory:

1.Electric eye loop control system

2.Outgoing catenary to assist and support the material

3.Hold down arms device

4.Hold up arm for sheet feeding in

5.Feeding line easily adjusts by advance worm gear screw jacks device

6.Touch screen control for leveling setting

7.The uncoiler contain the butterfly brakes air compressor

8.Uncoiler-inverter device

9.Feed and staightener rolls with a hard chrome finished

10.Up and down device for feeding in sheet loop

11.Coil tip flattness device

12.Coil holding arms

13.Hold down arms with motor

14.Electrical oil lubricating equipment

Parameter Name	Parameter Value
Operating mode	automatic
Product applications	sheet uncoiler
