Small robot: Lightweight body, mainly used in 3C electronics and other high-precision and precise production scenes, used in assembly, picking/placement, loading and unloading, tool operation, etc.
Medium robot: It adopts hollow arm and internal wiring design. It is mainly used for loading and unloading, deburring and burring of die-casting parts, and taking out injection molded parts.
Large robot: It adopts a high-strength, high-rigidity lightweight body, which is mainly used in injection molding, automotive, metal machinery and other fields for spot welding, polishing, handling, assembly, etc.

Characteristics

1. High performance: Repeated positioning accuracy can reach +-0.02mm. With hallow wall and internal line design. It greatly reduces the space interference of wrist movement, cable wear and splash damage which are caused by the external cable.
2. High protection level: IP67. Easy to deal with various working conditions an environments, with long lifetime.
3. Multifunction: Off-line simulation is supported, collision detection, multi-axis motion, absolute path retention, bus communication etc.
4. High stability: Integrated drive control system,less cable connection, quick response, strong anti-interference ability and high stability.

Application Industries

3C Electronics, Photo electricity, Food and Beverage, Mechanism, Injection, Automobile, Consumption Goods.

Parameter Name	Parameter Value
Type	articulated
Number of axes	6-axis
Function	handling for assembly pick-and-place loading unloading spot welding deburring
Application domain	for the food industry for the electronics industry for the automotive industry for injection molding machines
Protection level	IP67, IP40
Other characteristics	high-precision
Payload (kg)	0 - 8
Weight (kg)	29
