Calculates and distributes torque request to various control units (engine, e-motor, battery, transmission).

FACTS & BENEFITS

Off-the-shelf usage
Leads to reduced number of ECU variants
Communications gateway
All customer specific applications are possible for mass production

TECHNICAL INFORMATION

Core: Tricore TC375, TC387, opt. TC397
Flash size: up to 16 MB (OTA Flash optional)
Interfaces: 100 Mbit Ethernet, Up to 6 CAN-FD and 4 LIN, up to 5 SENT
Charging Interface: J1772AC / China GB/T - AC/DC
Inputs: Up to 21 analog or up to 21 digital
Drivers: 7 high- / 18 low-side / 6 configurable LS/HS outputs, up to 2 H-bridges
4 channels solenoid driver with configurable current control

Parameter Name	Parameter Value
Signal type	analog
Bus	Ethernet, CAN FD
Applications	for automotive applications
Number of inputs/outputs	4-channel
Mounting	shelf in-vehicle
Other characteristics	configurable
