8 analog input channels
thermocouple (type B / E / J / K / L / N / R / S / T / U), voltage (±80 mV)

High-accuracy digitization
24-bit ADC, 100 Hz sample rate per channel, 50/60 Hz mains rejection

Automatic linearization correction
optimal position of the interpolation points adjusted to the input range

Open thermocouple detection
detect broken wire, loose connection or thermocouple burnout

3-Way galvanic isolation
100 VDC channel to channel, 500 VDC channel to power supply and bank

Electromagnetic compatibility (EMC)
according to IEC 61000-4 and EN 55011

Parameter Name	Parameter Value
Signal type	analog
Applications	for thermocouples
Number of inputs/outputs	8 analog inputs
Mounting	DIN rail
