1 Analog input channel
measuring half and full bridge, IEPE-sensor, voltage, current, quarter bridge with completion terminal

1 Analog output channel
voltage (±10 V) or current (0 to 20 mA), 100 kHz update rate

High-accuracy digitization
19-bit SAR ADC (zero latency), 100 kHz sample rate

4 Digital inputs and 2 digital outputs
status, trigger, tare, alarm, command

Signal conditioning
32 virtual channels, linearization, digital filter, average, scaling, min/max storage, RMS, arithmetic, alarm

Additional RS 485 fieldbus interface
to control an 8 or 16 or 24 channel multiplexer for multi channel systems, 10Hz per channel

3-Way galvanic isolation
500 VDC channel to channel, channel to power supply, and bank

Parameter Name	Parameter Value
Signal type	digital, analog
Bus	Fieldbus
Number of inputs/outputs	4 digital inputs
Mounting	bridge
