I/O acquisition modules with 4 inputs / outputs: NXT-A4
Remote I/O acquisition modules compatible with ModBus RTU (RS485) and ModBus TCP (Ethernet) protocols.
Versatile IO analog module equipped with ModBus and CANBus
NXT-A4 is an IO analog module with 4 analogue inputs and outputs.
The I/O and communication ports are galvanically isolated to protect the entire circuit.
Thanks to the configurability of the inputs, each module is versatile and can be used for different types of probes.
Technical features:
4 configurable analog inputs (0-10V, 4-20mA, Pt100, Pt1000, NTC, PTC, Thermocouples)
4 analogue outputs 0-10V and 4-20mA
NFC interface for configuration
Optional WiFi / Bluetooth module
ModBus and CANbus I/O modules are specially developed for industrial applications. They are equipped with a DIN rail enclosure and are easy to install.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Signal type |
analog
|
| Bus |
Ethernet, Modbus RTU, RS485, Modbus, CANbus, Bluetooth
|
| Type |
remote
|
| Mounting |
DIN rail
|
| Other characteristics |
configurable
|
