-Modbus TCP slave / Ethernet/IP
-2 x Ethernet 10/100Mbps
-Up to 16 expansion slices
-Small slice type
-Light version

General description
Article number - 100-8112
Warranty - 2 year
Shock operating - IEC 60068-2-27 (15G)
Vibration resistence - Sine vibration (based on IEC 60068-2-6), 5 ~ 25Hz: ±1.6mm, 25 ~ 300Hz: 4G, Sweep rate: 1 octave/min., 20 cycles, Random vibration (based on IEC 60068-2-64), 10 ~ 40Hz: 0.0125g²/Hz, 40 ~ 100Hz: 0.0125 → 0.002g²/Hz, 100 ~ 500Hz: 0.002 g²/Hz, 500 ~ 2000Hz: 0.002 → 1.3 x 10-4g²/Hz, Test time: 1hrs for each test
Industrial emissions - EN 61000-6-4/A11: 2011
Industrial immunity - EN 61000-6-2:2005
Installation position - Horisontal, Vertical
Product certifications - CE, UL, FCC, RoHS, China RoHS, Reach
System power - Nominal supply voltage: 24VDC, Voltage range: 60℃: 18~32VDC, 70℃: 18~26.4VDC, Output current limitation: 1.5A, Reverse polarity protection
Power dissipation - Max. 40mA @ 24VDC
Current for IO module - 1.5A @ 5VDC
Isolation - System power to internal logic: Non-Isolation , System power I/O driver: Isolation
Field power - Nominal supply voltage: 24VDC, Voltage range: 60℃: 18~32VDC, 70℃: 18~26.4VDC, * Field Power Range is different depending on IO Module series. Refer to IO Module`s Specification.
Max current field power contact - DC 8A max
Weight - 75g
Module size - 22x109x70mm
Communication
Station type - Slave
Max expansion ports - 16 slices
IO data size - Input 128bytes / Output 128bytes
Max length bus line - 100 m
Max network nodes - Limited by Ethernet Specification
Baud rate - 100Mbps, Auto-negotiation, Full duplex
Settable node address - IP-address
Bus connection - 2 x RJ45

Parameter Name	Parameter Value
Signal type	analog
Bus	EtherNet/IP, RJ45, Modbus TCP
Type	network distributed
Applications	position
Mounting	DIN rail mounted
Other characteristics	slave
