> Inputs: 8 PNP, 24V 20mA
> Outputs: 4 PNP, 24V 0.8A
> Temperatures: the correct functionality of the node has been verified in a temperature range between 0 and 70 ° C
> Power supply: 24V (18-36V) - 0.5Adc
> Electrical Insulation: the inputs, outputs, and communication ports are insulated at 1kV
> Termination: the node needs a termination of 120Ω 1 / 4W already supplied and connected to one of the two communication connectors.
> Assembly: DIN bar
> Frontal H: 100 mm / L: 100 mm
> Depth P: 25 mm

Parameter Name	Parameter Value
Signal type	analog
Bus	CAN
Applications	temperature for packaging machines
Number of inputs/outputs	4-O 8-I
Mounting	DIN rail
Other characteristics	insulated
