About
- Optimizing design, compact, beautiful contour, long-term continuous working in rated working mode;
- High performance rare earth permanent magnet material, high power, large load;
- Excellent reverse potential sine, sine wave current drive and excel lent low speed performance;
- Motor inertia meeting machine feed driver;
- Flevel insulation material to extend motor l ife;
- Imported feedback components, original imported low-noise motor bearing to reduce vibration and noise;
- Full airproof and high rel iabi l ity to meet industry environment;
- Optimum matching with our AC servo driver to real ize optimum servo performance.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| AC/DC |
|
| Type |
synchronous
|
| Voltage (V) |
220 - 220
|
| Protection class |
IP65
|
| Configuration |
|
| Number of poles |
4-pole
|
| Applications |
with built-in encoder
|
| Other characteristics |
high-power
|
| Power (W) |
500 - 6000
|
| Torque (Nm) |
2.4 - 76
|
| Rotational speed (rpm) |
2000 - 4000
|
| Diameter (mm) |
95 - 110
|
