Applications

• Positioning and actuating drive for drive tasks with or without transmission
• For intermittent operations
• Control drive for continuous operation

Connection cable
Nominal cross-section of copper conductor 1.5 mm2
Power connector in size 1

BENEFITS
• Extremely high standstill torques based on the axle height
• High torques and power density
• High overload capacity
• Exceptional dynamism with acceleration values of up to 160,000 rad/s²
• Protection class IP54

Parameter Name	Parameter Value
AC/DC	AC
Type	synchronous
Protection class	IP54
Cooling mechanism	liquid-cooled forced-ventilated
Applications	industrial
Other characteristics	high-torque variable-speed
Power (W)	340 - 340 590 - 590
Intensity (A)	0.9 - 2.18
Torque (Nm)	0.54 - 0.54 0.94 - 0.94 2.1 - 2.1 5 - 5
Rotational speed (rpm)	6000 - 6000
