Voltage:230V
Torque:0.77N.m
Power:560W
Speed:21000rpm
1. The overall height of the motor to reduce 46mm ~ 51mm; the height of the finished machine can be reduced 100mm ~ 150mm;
2. The motor efficiency is increased by 6%;
3. Working torque (@:10000RPM): increase by 14.5%; stall torque (@:0RPM): increase by 24.6%;
4. Working temperature rise (@1200W): reduce 20K;
5. The deflection bearing distance is reduced by 47.4%~52.5%, and the vibration (amplitude) is reduced by 50%;
6. The magnetic circuit is more evenly distributed;
7. The average noise is reduced by 5dB(A);

Parameter Name	Parameter Value
AC/DC	AC
Type	universal
Voltage (V)	230 - 230
Applications	for household appliances
Power (W)	560 - 560
Torque (Nm)	0.77 - 0.77
Rotational speed (rpm)	0 - 21000
