Standard Voltages: 115/230 Vac & 24 Vac 50/60 Hz
Insulation Class: Class A (105°C)
Lead Wire: 4 leads 22AWG (approx. 9 inches [228.6 mm])
Shaft Bearings: Sleeve bearings
Recognition: E53578(N), Component-Impedance Protected Motors
Capacitor is required for operation. Capacitor supplied with 115 Vac motors.
Note: Typical data subject to change without notification

Parameter Name	Parameter Value
AC/DC	AC
Type	synchronous
Voltage (V)	220 - 230
Configuration	permanent magnet capacitor
Other characteristics	direct-drive with sleeve bearing
Power (W)	5 - 5 7 - 7
Torque (Nm)	0.468 - 0.468 0.612 - 0.612
Rotational speed (rpm)	250 - 250
Diameter (mm)	55 - 55
Operating temperature (°C)	-10 - 40
