Technical features:
• Single or three phase asynchronous motor
• Permanently oil lubricated
• Thermal cut-out
• 2 directions of rotation
• Class B insulation
• IP44 protection
• Temperature working range: -20°C to +85°C
• Relative humidity < 95%

Options:
• Output shaft according to specifications
• Inrush current or lack of current brake
• Voltages and frequencies upon request
• 2 mountings available (foot or face)
• Classe F insulation
• IP55 protection

Parameter Name	Parameter Value
Motor type	AC
Type	spur
Shaft orientation	coaxial
