Terminal box
Hollow shaft stainless steel
Any transmission
Thermal protection
IP 54
Depending on the gear ratio, the Compacta MR6 shaft-mounted gear motor with the optional integrated control unit version provides an output speed of 2.9 to 100 rpm and a nominal torque up to 60 Nm. The drive motor has a compact design, making it ideal for applications in reversing mode with narrow installation conditions. Standard drive motors are splash-protected (IP54), optionally jet-protected (IP65) and explosion-protected in accordance with ATEX 95. Additional options increase the number of application options substantially.

Furthermore, design-related adjustments are also conceivable for larger quantities so that the drive motor can be adapted individually to certain requirements. You can find projects that have already been implemented here.

Parameter Name	Parameter Value
Motor type	AC three-phase
Type	worm
Shaft orientation	right angle
Power (W)	100 - 500 50 - 100
Torque (Nm)	10 - 20 20 - 50 50 - 100 100 - 200 200 - 500 500 - 1000 1000 - 2000
Product applications	industrial
Other characteristics	compact hollow-shaft IP54 shaft-mounted IP65
Operating temperature (°C)	0 - 40
