General
Optimised for the rough environment of the rotor hub on a wind
turbine, the MotionController GEL 8400 meets all requirements
arising in installation locations worldwide - whether onshore or
offshore. As the Hot Climate Version (HCV) in the hot and humid area of South China or as the Cold Climate Version (CCV)
for -20 °C temperatures at 1500 m altitude in the Central Asian
Plateau. As the successor to the proven GEL 823x and GEL
825x, the new GEL 8400 combines years of experience with a
performance increase in this product family.
Optionally with Remote Service WEB
FTP, HTTP communication via web browser
■ Condition monitoring of the current actual values
■ Reading and writing parameters.
■ Reading saved faults
■ Interface to LB Graph
■ Remote Update, online update of the firmware
■ Remote service log book
Features
■ Expanded temperature range - 40 °C to + 70 °C
■ Robust, resistant to shock and vibration
■ Compact controller, CPU, LCD display,
keyboard and I/Os
■ 30 digital inputs / 15 digital outputs
■ 3 analogue inputs / 3 analogue outputs
■ 4 PT100 inputs
■ 3 SSI inputs / 6 incremental inputs (5 V / 24 V)
■ Serial interfaces: 1 x RS 232 C / RS 422/485, 1 x RS 232 C
■ 2 x CANopen onboard
■ Optional: EtherNet/IP interface module
Advantages
■ Optimised for rough environments
■ Technically improved successor to the field-proven controller
GEL 823x and GEL 825x
Fields of application
■ Wind power (onshore, nearshore, offshore)
■ Tidal power plants
■ Robust industrial environments

Parameter Name	Parameter Value
Number of axes	6-axis
Technology	CNC
Other characteristics	compact
Product applications	for wind turbine
