If the accuracy is less than 3um, the measurement result is the true value without any compensation.
Z axis can focus automatically and adapt to different thickness products.

Capacity
More than 20000 tablets can be measured in one day.

Fast
Measure all image sizes< Zero point three Seconds / piece

Special inspection
Flatness, height, thickness and profile.

1. Marble structure, stable and reliable.
2. Taiwan precision linear guide rail and grinding level ball screw, with Panasonic servo motor, closed-loop control, better precision.
3. Automatic zoom lens, changing magnification without reselection of scale.
4. German Heidelberg grating scale, resolution 0.0005mm .
5. Japan Omron laser.
6. Large magnification measurement screen.
7. High quality optical system and high resolution camera make the picture clearer.
8. Four ring and eight zone LED ring surface cold light source, contour light source and coaxial light source, with adjustable brightness.
9. Mouse and handle operation, simple and easy to use.
10. Self developed automatic CNC measurement system with friendly interface and powerful function.

Parameter Name	Parameter Value
Technology	3D CNC
Applications	surface
Sector	industrial
Other characteristics	measurement non-contact
