Structure Shape B5 / B3 / B35 / B34
Terminal Box Position Top
Frame Size 063
Frequency 50 Hz
Moment of Inertia 0.00012 kg.m²
Load 4/4 3/4 1/2
Efficiency 67.5 % 67.5 % 67.5 %
Power Factor 0.77
Insulation Class F (155°C)
Temperature Rise B (80°K)
Maximum Altitude 1000 m
Methods of Cooling IC 411
Sound Pressure Level 51 dB(A)
Vibration Class A
Duty Cycle S1 (Continuous Running Duty)
Service Factor 1.15
Direction of Rotation Clockwise
Motor Weight 3.80 kg
Bearings DS (6201 ZZ) NS (6201 ZZ)

Parameter Name	Parameter Value
AC/DC	3-phase
Type	induction
Voltage (V)	460 - 230
Protection class	IP55
Configuration	aluminum squirrel cage
Number of poles	4-pole 2-pole
Cooling mechanism	self-ventilated
Applications	for industrial applications
Other characteristics	low-voltage high-torque IE2
Power (W)	120 - 290
Torque (Nm)	0.61 - 0.61 0.82 - 0.82 0.85 - 0.85 1.23 - 1.23
Rotational speed (rpm)	1385 - 3395
Diameter (mm)	119 - 119
Operating temperature (°C)	-15 - 40
