The RS485 I/O Controller is a versatile LED display control board that connects to the RS485 Bus of Pertronic Fire Alarm panels as an LED Mimic type. A hardware peripheral board allows it to be used for a variety of multipurpose LED display solutions such as F120 Fan Control indication or Site Mimic displays. The RS485 I/O Controller may be used as part of the Fire Alarm Panel or as a device remote from the panel. The 24-Way and 48-Way Open-Collector boards may be used in conjunction with the LED Address Controller board to provide a cost effective and easy solution for controlling large numbers of connected LEDs and/or Relays.

Features

Robust microprocessor based design
Removable plug-in terminals for quick and simple installation
Connectors accept 0.8mm2 to 3.3mm2 cable
Onboard Lamp Test and Base address check
Standard Pertronic display peripheral interface
24-Way or 48-Way Open Collector output peripheral card
10 x 24-Way or 10 x 48-Way Open Collector boards may be daisy-chained to provide up to 480 outputs maximum
8-Way Common Relay Board converts open collector outputs to relay contacts
RS485 Mimic Address Jumper links
Rotary decade switches for Start LED Address offset settings
Address Offset to >LED 2000
Pertronic RS485 communications as LED Mimic device

Parameter Name	Parameter Value
Number of axes	3-axis
Technology	embedded
Product applications	fire alarm display
