● Red / White build-in illumination;
● Support Software Trigger/Hardware Trigger/Free Run, etc.;
● Gigabit Ethernet interface, providing 100M bandwidth;
● Abundant I/O interfaces, Ethernet, RS232, GPIO interface;
● DC 5V~24V power supply, low power consumption, less than 2.5W;
● Abundant code reading types, CODE128/ EAN/ CODE39/ CODE93/ CODEBAR /ITF25 /DM /QR, etc.;
● Integrated red/white dual light, all-in-one design, support manual fousing
● Software trigger/External trigger/Free run modes
● Indutrial Ethernet port up to 100Mbps bandwidth
● Abundant IO interfaces such as Ethernet, RS232, GPIO
● DC 12~24V power supply, consumption less than 2.5W
● Support decoding 1D: Code 39,Code 93,Code 128,CodaBar,EAN8,EAN13,UPCA,UPCE,ITF25 etc.; 2D: QR/DM/DPM
Resolution
1280 x 960
Max. Frame rate
20fps
Sensor Type
1/3", CMOS
Pixel Size
3.75 x 3.75
Trigger Mode
Support Software Trigger/Hardware Trigger/Free Run, etc.
Software
EasyID
Certifications
CE, FCC
Function
Abundant code reading types (1D: Code128/Code39/Code93/EAN etc.;2D: QR/DM etc.)
Operating Distance
70mm
FoV
42 x 32mm
Max. Read Speed
20 pcs/s
Min. Resolution
1D code 0.05mm/ 2D code 0.13mm
Light Source type
Red / White build-in illumination
