About
● CMOS series product, high-speed capture
● Built-in deep learning algorithm, efficient and powerful algorithms
● Support software trigger/ hardware trigger/ free run modes
● GigE, up to 1Gbps bandwidth
● Abundant I/O interfaces, RS232,3Opto-isolated input, 3Opto-isolated outputs
● Industrial M12 connector, IP67
Resolution
5440 × 3648
Max. Frame rate
15 fps
Sensor Type
1"，CMOS
Shutter Mode
Rolling
Pixel Size
2.4 × 2.4
Lens Mount
C-MOUNT
Trigger Mode
Software trigger/External trigger/Free run modes
Software
EasyID
Certifications
CE，FCC，KC
Function
lD: Code 39，Code 93，Code 128，CodaBar，EAN8，EAN13，UPCA，UPCE，ITF25 etc. and 2D: QR/DM/DPM; Quality Evaluation: 1S0/IEC 29158(AIM-DPM), 1S0/IEC 15415, 1S0/IEC 15416
Connector
2 Industrial connectors support GigE and GPIO
Network Port
Code-A,GigE
GPIO Interface
12Pins GPIO，RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs
Communication Mode
RS232, Ethernet
Communication protocol
SDK,TCP Client,FTP,TCP Server,RS232,Profinet,Modbus,EtherNet/IP etc.
LED Indicator
Power,Ethernet,Trigger
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
|
