About
● Light-integrated design makes red/white/blue illumination optional, support control separately
● Support different focal lengths, electrical auto focus and one-click auto training
● GigE interface, IP65 protection level
● Abundant IO interfaces such as Ethernet, RS232, GPIO, support multiple communication protocols
● Support various code formats and evaluations of code quality
● Built-in deep-learning algorithms and multi-parameters polling to ensure effects of complex applications
Resolution
1440×1080
Max. Frame rate
60 fps
Sensor Type
1/2.9"，CMOS
Pixel Size
3.45×3.45
Lens Mount
M12, auto focus
Trigger Mode
Software trigger/External trigger/Free run modes
Software
EasyID
Certifications
CE，FCC，KC
Function
lD: code 128, code 39, code 93, EAN etc. and 2D: QR/DM/DPM; Quality Evaluation: 1S0/IEC 29158(AIM-DPM), 1S0/IEC 15415, 1S0/IEC 15416
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
|
