Minimum resolution of 17 pm when combined with the BS series. Supporting various serial and binary outputs.

High response speed :
400 mm/s (When connected with BS series)
700 mm/s (When connected with BH series)
1,100 mm/s (When connected with BL series)
Maximum resolution :
0.4 nm (When connected with BL series)
31.25 pm (When connected with BH series)
17 pm (When connected with BS series)
Includes automatic signal compensation
A/B quadrature output (standard : 4 divisions) (binary output axis 1 or 2 type)
BS series : 34.5 nm, BH series : 62.5 nm, BL series : 100 nm
Max. divisions : 8,000 (When connected with BS and BH series) (special model)

Parameter Name	Parameter Value
Options	2 channel
